Product Description
Application: This Rubber Insulated Cable product is suitable for movable electric appliances and excavators used in mines.
Operating Temperature: Max permissible continuous operating temperature of conductor shall not exceed 65oC.
Bending Radius: 6D,D = Actual outer diameter of cable (mm)
Standard: MT818- 19991 or other standards required by customers.
Packing: Steel/wooden reel,,wooden reel or steel reel.
TYPE MY
1.Power conductor
2.Rubber insulation
3.Rubber filler
4.Ground conductor
5.Rubber sheath
Cable Type,Description and Rated Voltage
|
Type |
Description |
Rated Voltage |
|
MY |
Movable rubber sheathed flexible cable for mining purposes |
0.38/0.66kV |
|
MYQ |
Light type movable rubber sheathed flexible cable for mining purposes |
0.3/0.5kV |
|
MYP |
Movable screened rubber sheathed flexible cable for mining purposes |
0.38/0.66kV |
|
MC |
Flexible rubber sheathed excavator cable |
0.38/0.66kV |
|
MCP |
Flexible screened rubber sheathed excavator cable |
0.38/0.66kV |
|
MZ |
Rubber sheathed drill cable for mining purpose |
0.3/0.5kV |
Supply Range
|
Type |
Rated Voltage |
No of Cores |
Nominal Area of Conductor sq.mm |
||
|
KV |
Power Core |
Ground Core |
Control Core |
||
|
MY |
0.38/0.66 |
1 3+1 |
50 to 400 4 to 70 |
4 to 25 |
- |
|
MYP |
0.38/0.66 |
3+1 |
4 to 70 |
4 to 25 |
- |
|
MYQ |
0.3/0.5 |
2,3,4,7, 12 |
1.0 to 2.5 |
- |
- |
|
MC |
0.38/0.66 |
3+1+3 |
4 to 50 |
4 to 10 |
2.5 to 4 |
|
MCP |
0.38/0.66 |
3+1+3 |
4 to 50 |
4 to 10 |
2.5 to 4 |
|
MZ |
0.3/0.5 |
2.5~4 |
2.5 to 4 |
2.5 to 4 |
2.5 to 4 |
Rubber Insulated Cable is a type of electrical cable known for its robust construction and exceptional performance in diverse environments. Comprising high-quality rubber insulation, these cables provide reliable electrical conductivity while safeguarding against external factors like moisture, heat, and abrasion.
TYPE MC
1.Flexible copper conductor
2.Natural rubber insulation
3.Bare copper ground conductor
4.Control conductor
5.Natural rubber sheath
Whether it's in industrial, commercial, residential, renewable energy, or infrastructure projects, Mingda cables deliver reliable connectivity and performance
