Heat Resistant Fabric Conveyor Belt China Conveyor Belting Exporter High temperature-heat resistant conveyor belt
PRODUCT DESCRIPTION
Heat Resistant Grade of Heat Resistant China Conveyor Belting Exporter
Four grades divided according to different testing temperatures:
| Grade | Testing temperature(≤) |
| T1 | 100℃ |
| T2 | 125℃ |
| T3 | 150℃ |
| T4 | 175℃ |
Physical Properties of Rubber Cover of Heat Resistant Fabric China Conveyor Belting Manufacturer
| Item | Grade | ||||
| T1 | T2 | T3 | T4 | ||
| Changing range allowed | |||||
| Hardness | Difference between before-aging and after-aging (IRHD) | +20 | +20 | ±20 | ±20 |
| Maximum value after aging (IRHD) | 85 | 85 | 85 | 85 | |
| Tensile strength | Change rate of property/ % | -25 | -30 | -40 | -40 |
| Minimum value after aging/ MPa | 12 | 10 | 5 | 5 | |
| Breaking elongation | Change rate after aging/ % | -50 | -50 | -55 | -55 |
| Minimum value after aging/ % | 200 | 200 | 180 | 180 |
Baoxiang High temperature-heat resistant conveyor belt: mainly used in metallurgy, construction and other industries, conveying sinter, coke, cement clinker and other high-temperature materials, material temperature does not exceed 800℃, belt surface temperature does not exceed 220℃.
Features: epDM rubber is used as the covering layer, and the skeleton material is made of domestic special high-temperature resistant canvas. The unique formula design solves the key problems due to the high saturation of EPDM rubber, poor adhesion and low inter-layer adhesion. With a light body, long life (about 2-4 times), good heat resistance characteristics.
Heat resistant conveyor belt is made of multi-layer rubber cotton canvas (poly-cotton) covered with high temperature or heat resistant rubber, bonded together by high temperature vulcanization, suitable for conveying hot coke, cement, slag and hot casting below 175℃.
Interlayer bonding strength:
| Item | Cloth layer | Cover with cloth layer | |
| Thickness of covering layer ≤1.5mm | Thickness of covering layer ＞1.5mm | ||
| Longitudinal test average value≥ | 8.0 | 7.0 | 12 |
| longitudinal test lowest peak≥ | 8.0 | 6.5 | 11 |
Heat - resistant (high - temperature) conveyor belt selection, product use matters needing attention:
1. Selection of heat-resistant conveyor belt:
The type of heat-resistant belt is selected according to the temperature, surface structure and viscosity of materials transported by the heat-resistant belt. For example, when the conveying temperature of sintered ore, coke and other large materials is 150℃, and the contact area between the material and the belt surface is small, the belt surface temperature is maintained at 60-80℃; When conveying cement powder and other materials with low viscosity, the temperature difference between the material and the temperature of the belt surface is very small.
The surface temperature is closely related to the service life of the tropics. It directly affects the glue and the core layer, the bonding strength between the core layer, the wear resistance and crack resistance of the glue. The type of topics should be selected after fully investigating and measuring the surface temperature of the belt and other service conditions.
Thicker covering glue is an important condition to ensure the tape has a long service life. It is recommended that the thickness of the cover glue resistant to tropics is 6-9mm for gluing and 2-4mm for gluing.
2. Key points for use of heat-resistant conveyor belt:
The surface temperature of the whole strip should be continuously measured, recorded and monitored to avoid unnecessary temperature rise.
To the material tape forced cooling (preferably on the layer of water flushing);
Keep the conveying material evenly distributed according to the bandwidth, not excessively concentrated;
Prevent the presence of oil (trace oil in the cooling water) from damaging the belt more than the heat itself;
A belt containing hot material shall be removed promptly when it ceases to operate;
It is better to use hot glue connection for the connection of tropics.
Baoxiang provides rubber belting for sale, we are committed to the alkaline resistant conveyor belt, material handling conveyor belt series, rich experience, welcome to consult.
