Hydraulic Knuckle Boom Telescopic Mobile Crane with Max. Lifting Capacity 25ton
Product Description
Min Order Quantity：1 Set
Supply Ability：2000 unit/month
Port：CHINA
Delivery Lead Time：in 30days
Country/Region：China
City：Haikou
Product Attributes
- - Model Number QY25KC
- - Place of Origin China
- - Supply Type OEM Service
- - Condition New
- - Color Yellow
- - Application hoist
- - Feature Truck Crane
- - Max. Lifting Height 43.4m
- - Max. Lifting Load 25ton
- - Rated Loading Capacity 25ton
- - Span 6.4m
- - Related Keywords QY25KC, truck crane, crane 25ton, xcmg crane, mobile crane
Description by Manufacturer
Outrigger: 4 outriggers, H-shaped arrangement, lateral and vertical outrigger controlled by the hydraulic control. Control levers are located on both sides of the chassis, with a luminous level gauge equipped, with the fifth jack and the vertical outrigger has two-way hydraulic lock. Outrigger float dimension: 400mm;Max outrigger reaction force:323kN;
Engine: SC9DF300.1Q5, in-line six-cylinder water-cooled EFI Diesel engine manufactured by Shanghai Diesel engine Co., rated power 221KW/2200rpm, Max. Torque 1250N.m/1400rpm, the national V emission standards. Fuel tank: 320L;
Gearbox: FAST manually mechanical control, 9-speed available, synchronizer is equipped;
Axles: High strength axle with reliable performance from Meritor. 2nd axle and 3rd axle for driving;
Suspension: Front suspension; longitudinal leaf spring suspension with barrel shock absorber; Rear suspension: V-type thrust rod structure, and rubber spring suspension;
Tires: 10tires and 1 spare tire front axle is equipped with 11.00-20 single tire, middle axle and rear axle are equipped with double tire;
Steering: Mechanically steering mechanism with hydraulic power assisted;
Hydraulic system: exclusive matching throttle with compensation afterwards and load-sensitive technology results in the higher stability of the lowest system flow, more reasonable system rigidity, more outstanding fine control and smoothness. With double-pump confluence of hoisting, elevating and telescoping, the working speed of main and auxiliary winch can reach 135m/min, which improves the working efficiency greatly.
Boom: 4-section, U-shape cross section, welding structure. Boom length: 10.6m-35m;
Jib: 1-section, lattice jib, weed structure. Fixed Jib Length: 9m;
| Item | Unit | Descrition |
| Dimension | mm | 12940*2550*3400 |
| Wheelbase | mm | 4500+1350 |
| Total weight in travel | kg | 30200 |
| Engine | / | SC9DF300.1Q5 |
| Power/Speed | kw/rpm | 221/2200 |
| Rated torque | N.m | 1250/1400 |
| Max. travel speed | km/h | 90 |
| Total Rated lifting capacity | kg | 25 |
| Min. rated working radius | m | 3 |
| Outrigger Span (longitudinal) | m | 5.5 |
| Outrigger Span (lateral) | m | 6.4 |
| Base boom hoist height | m | 10.2 |
| Full-extended boom+jib | m | 43.4 |
| Base boom length | m | 10.8 |
| Full-extended boom+jib length | m | 44 |
| Max. slewing speed | r/min | 2.5 |
Price
- Price US$ \ 100000 ~ 120000 / Set
Packaging & Shipping
- - PackingRO RO shipment
- - Packaging Size12940 x 2550 x 3400 ( Millimeters)
- - Package Weight 30200 ( Kilograms )
- - Delivery Lead Timein 30days
- - Minimum Order 1 Set
- - Supply Ability2000 unit/month
- - Delivery PortCHINA
