Motor Drive High Pressure 3D Rotary Tank Cleaning Nozzle

Product Description

Min Order Quantity:1 Piece

Supply Ability:10000 pcs per month

Delivery Lead Time:10 days

Country/Region:China

City:Guangzhou

Product Attributes

  • - Model Number MD series 3D rotary tank cleaning nozzle
  • - Place of Origin China
  • - Material 316LSS
  • - Operating pressure 3-100 bar
  • - Application rinsing and cleaning
  • - Max. tank diameter 4m
  • - Connection thread or flange
  • - Related Keywords tank cleaning nozzle, tank washing nozzle, spray nozzle, tank cleaning machine

Description by Manufacturer

Motor drive high pressure 3D rotary tank cleaning nozzle

Model MD series rotary tank cleaning nozzle
Material 316LSS
Connection thread or flange connection
Recommanded pressure 3-100 bar
Temperature 95°
Max. tank diameter 4m
Application rinsing and cleaning of tanks / containers
Filteration Line strainer with a mesh size of 0,3 mm/50 mesh

Design features :

MD series are driven by the motor with external gear and provides 360° impact indexed coverage for the cleaning of the inside of tanks and process vessels.

1.Using dynamic seal at leakage point to reduce leakage, only 3% leakage, thus save cleaning fluid.
2. The nozzle have a unique steady flow design which can make the jet be more concentrated, greater impact.
3. Driven by external motor, thereby reducing the pressure loss of water flow, resulting in higher water impact.
4.Compact build ideal for small openings

Common application:

Model MD series is a highly versatile machine and is applicable in most all types of
tanks for process, storage, and transportation. It can be used as a portable unit or permanently mounted.

e.g: in food industry, beverage industry, pharmaceutical industry and chemical industry

Product photo:

Performance Data:

Dimension:

Application:

D25-1/2" rotary spray heads are used to rinse and clean 1000L IBC totes/ tanks.

Product Categories

Tank cleaning nozzles Full cone nozzles

Air atomizing nozzle Air nozzles

Flat fan nozzles Hollow cone nozzles

Company photos:

Exibition photos:

Company information

Guangzhou Cleaning-spray Equipment Co., Ltd is one of leading company in China specialized in manufacturing and selling tank cleaning nozzles, industrial spray nozzles and other spray product which are widely used in Pharmaceutical, Chemical, Food and Beverage and other industry. We can provide you with optimal solution according to your requirement.

Our Services


1. Reply your inquiry within 24 hours.
4. Best after-sale service. We accept return if the products is not right specification or damaged when arrived.
5. Payment Term:T/T , Western Union, Secure payment
6. Delivery Term: China Post/ TOLL/ DHL/ UPS/FEDEX Express; Air/ Sea Transportation
7. All products can be customised.

FAQ



1,Can the products be customized?
Yes, we accept OEM, just send us your layout or actual sample, we can arrange production according your design.

2,Is the MOQ fixed ?
For mass production orders,the MOQ cannot be lowered according to production requirements.For stock items,order quantity can be negotible.

3,How to order?
Please send one RFQ to us, our sales will confirm with you about the specification or other required things, then will send an official invoice to you via mail, which will be included the details of your order and bank information of our company.

4,How to pay?
We accept the payment via ESCROW, T/T (bank transfer) and Western Union, please inquire us about the details in advance.

5,How long about the production leadtime?
Different products and quantities have different procedures and different timing,normally it needs about 7-14 working days.

6, How to Deliver?
By air, by sea or by express(Fedex, DHL, UPS, TNT etc)

7,How to return ?
Acceptable to the returns when you receive the products because of the following reasons.

1. Product was damaged, lost or missed
2. Different specification from required one.

Before ordering, please select a suitable product for you. As you know, all of us don't expect the return. If your return is the result of our error (you received an incorrect or defective item, etc.) we will cover the cost of return shipping. Please note that you are responsible for the cost of shipping for returns not due to our error.

Contact info:

Company: Guangzhou Cleaning-spray Equipment Co., Ltd
Address: No . 168 ,the second Industrial Zone, Xia village 5th Community, Jia He Street, Baiyun District, Guangzhou,510440 Guangdong, China

Website: www.cleaning-spray.com

TEL: 0086-(0)20-36269960

Fax: 0086-(0)20-36269969

Phone / whatsapp / wechat: 0086 13725126489

Contact name: Fiona Ye

Price

  • Price US$ \ 1200 ~ 1600 / Piece

Packaging & Shipping

  • - Packingcarton
  • - Packaging Size120 x 30 x 30 ( Centimeters)
  • - Delivery Lead Time10 days
  • - Minimum Order 1 Piece
  • - Supply Ability10000 pcs per month
