Foldable Mesh Container 1000*800*840mm
This model is the B series of , which we call Foldable Mesh Container B1. The size of this series of Foldable Mesh Container is 1000*800*840mm. There are two types of mesh spacing: 50*50mm and 50*100mm. This model is 50*50mm.
Product Description
[1000*800*840] Foldable Mesh Container B series Zhihong storage cage
[Outer diameter size]: 1000*800*840
[Inner diameter size]: 950*750*700
[Wire diameter]: 5.8mm
[Product load bearing]: 1200KG
[Grid]: 50x50mm
[Cage weight]: 44.8KG
[Number of stacking layers]: 4 layers
This model is the B series of conventional storage cages, which we call Foldable Mesh Container B1. The size of this series of Foldable Mesh Container is 1000*800*840mm. There are two types of mesh spacing: 50*50mm and 50*100mm. This model is 50*50mm.
Collapsible Wire Mesh Container, also named as foldable mesh container, butterfly cage, wire mesh container, wire basket, warehouse cage, foldable crate, metal wire logistics container, are a type of popular industrial wire container, with sturdy, durable, portable, foldable, collapsible, stackable characters, they are widely used for bulk materials handling, transport and storage, etc.
Collapsible Wire Mesh Container Characteristics:
◎ Steel wire structure with electrolytic zinc coating finish
◎ Foldable to save space during transport and storage
◎ Stackable in folded and unfolded position
◎ Half-panel foldable on the long side
Foldable Mesh Container Parameters:
| Models | External Dimension(mm) | Internal dimensions(mm) | Wire(mm) | Mesh(mm) | foot height(mm) | N.W.(kg) | Meas.(㎡) | Load-bearing(kg) |
| A-1 | 800*600*640 | 750*550*500 | 50*50 | 5.8 | 100 | 28 | 0.22 | 1500 |
| A5.6 | 800*600*640 | 750*550*500 | 50*50 | 5.6 | 100 | 25.9 | 0.22 | 1000 |
| A5.2 | 800*600*640 | 750*550*500 | 50*50 | 5.2 | 100 | 22.4 | 0.22 | 600 |
| A4.8 | 800*600*640 | 750*550*500 | 50*50 | 4.8 | 100 | 20.6 | 0.22 | 500 |
| B-1 | 1000*800*840 | 950*750*700 | 50*50 | 5.8 | 100 | 44.5 | 0.52 | 1500 |
| B5.8 | 1000*800*840 | 950*750*700 | 50*50 | 5.8 | 100 | 43 | 0.52 | 1500 |
| B5.6 | 1000*800*840 | 950*750*700 | 50*50 | 5.6 | 100 | 41.1 | 0.52 | 1000 |
| B5.4 | 1000*800*840 | 950*750*700 | 50*50 | 5.4 | 100 | 37.5 | 0.52 | 800 |
| B5.2 | 1000*800*840 | 950*750*700 | 50*50 | 5.2 | 100 | 34.6 | 0.52 | 600 |
| B4.8 | 1000*800*840 | 950*750*700 | 50*50 | 4.8 | 100 | 31.2 | 0.52 | 500 |
| B4.8(small) | 1000*800*840 | 950*750*700 | 50*100 | 4.8 | 100 | 27.6 | 0.52 | 500 |
| C-1 | 1200*1000*890 | 1150*950*750 | 50*50 | 5.8 | 100 | 60 | 0.84 | 1500 |
| C5.6 | 1200*1000*890 | 1150*950*750 | 50*50 | 5.6 | 100 | 56.2 | 0.84 | 1000 |
| C5.6(middle) | 1200*1000*890 | 1150*950*750 | 50*50 | 5.6 | 100 | 53.6 | 0.84 | 1000 |
| C5.6(small) | 1200*1000*890 | 1150*950*750 | 50*100 | 5.6 | 100 | 46.6 | 0.84 | 1000 |
| C5.2 | 1200*1000*890 | 1150*950*750 | 50*100 | 5.2 | 100 | 39 | 0.84 | 600 |
| C4.8(big) | 1200*1000*890 | 1150*950*750 | 50*50 | 4.8 | 100 | 42.5 | 0.84 | 500 |
| C4.8 | 1200*1000*890 | 1150*950*750 | 50*100 | 4.8 | 100 | 35.8 | 0.84 | 500 |
The size can be customized and also you can choose the diameter（φ） and the distance of the wire.It will be a little complex .Please click inquire and connect to us so we can do it as you want.
Benefits and Uses of Foldable Mesh Container:
Foldable Mesh Containers or cage containers make handling, transporting and storing bulk partsand materials easy. Collapsible Wire Mesh Containers are reusable containing systems that deliver high visibility savings. These tough, welded wire containers provide quick content identification, promote better material flow, and more efficient stock control.
Mesh Container Folding Method:
Foldable Mesh Container Features:
◎ Easy to clear, sort and count due to the uniform specification and fixed capacity.
◎ Sturdy and durable, easy to carry and recyclable .
◎ Can be stowed in rack and assembly line and can also be stacked.
◎ The wire container with casters can be movable.
◎ The wire container with PP slab and steel slab can avoid the missing of small spare parts.
◎ The wire container with the enlarged mesh space can be used to deposit the paper box and light goods.
◎ Can not only used in the workshop but also in supermarket for sales promotion and storage.
Foldable Mesh Container Application
EVERGREAT supply foldabel wire mesh cage for material handling and storage in supermarket, shops and industries,the ideal choice for better bulk material handling.
