Diode Laser vs CO2 Laser vs Fiber Laser: Which Laser to Choose?



1) Materials the Lasers Can Cut and Engrave

 The decision to select a type of laser depends on the materials you want to engrave and cut and what the laser machine can do.

First of all, if a laser can cut certain materials, it can also engrave them. But if a laser is engraving certain materials, it is not necessary it will be able to cut them. For cutting, high power is needed compared to engraving.

a. Dioder Laser Engravers

If you want to start a small business, a diode laser is a suitable option as it can cut and engrave a wide range of materials we commonly use.

Diode laser machines can easily cut 5-8mm thick solid wood, 5-10mm thick plywood, 2-5mm thick acrylic, cardboard, paper, and leather. These are the common materials that almost all laser diode machines can cut according to their power.



The materials that can be engraved by diode laser machines are plywood, solid wood, acrylic, paper, leather, steel, glass, ceramics, and a few more materials.



Engraving

Cutting

Solid wood

Solid Wood

Plywood

Plywood

Glass/Ceramics

Cardboard

Steel

Paper

Leather

Leather

Paper

Acrylic

Acrylic



 b. CO2 Laser Engravers



CO2 laser machines are better than diode laser machines in terms of cutting materials. They can cut and engrave a broader range of materials.

A CO2 laser can cut wood, acrylic, foam, cardboard, leather, plastics, glass, fabric, rubber, paper, Corian, and MDF.

The materials that a CO2 laser can engrave are acrylic, wood, leather, plastic, fabric, glass, rubber, brick, ceramics, bone, aluminum, and steel.

Engraving

Cutting

Solid wood

Solid Wood

Plywood

Plywood

Glass/Ceramics

Cardboard

Steel

Paper

Leather

Leather

Paper

Acrylic

Acrylic

Foam

Brick

Plastics

Rubber

Glass

Fabric

Fabric

Bone

Rubber

Aluminum

c. Fiber Laser Engravers



Fiber laser machines can cut and engrave most metals and some non-metals. It cuts and marks metals that other laser machines cannot do. These machines are very powerful, so they can easily cut a wide range of metals.

But primarily, these lasers are used for marking and engraving. They can engrave aluminum, brass, copper, ceramics, tungsten, chrome, painted metal, fiberglass, carbon fiber, nickel, plastics, wood, rubber, silver, gold, stainless steel, and synthetic leather.

Engraving

Cutting

Aluminum

Metal sheets

Brass

Leather

Copper

Wood

Ceramics

Acrylic

Tungsten

Chrome

Painted Metal

Fiber glass

Carbon fiber

Nickel

Plastics

Leather

Rubber

Silver

Gold

Steel

2) Laser Power

Beginners need to understand a few things while considering the power of a laser machine. There are three types of power ratings mentioned for laser machines. The three types are laser optical/output power, laser electric power, and machine power.

Machine power refers to the input power of the machines. It does not represent the power of a laser.

The second one is the laser electric power, which is the input electrical energy taken by the laser module. The power is related to the laser module, but it does not represent the ability of the laser to engrave and cut an object. However, it can be used to understand the electricity consumption of the laser module.



The most important power is the laser optical/output power. It is the power that shows the ability to cut and engrave materials. The laser coming out of the module has optical power, and buyers need to see this power to understand what a laser machine can do.

The machine power rating is always the highest, and then comes the laser electrical power, and finally the laser optical power. For instance, a diode laser machine has an optical power of 10W, electric power of 40W, and machine power of 60W.

Beginners get confused between laser electrical power and optical power. Some companies also scam people by telling them the electrical power instead of optical power. Thus, you always need to see the optical power of the machine for comparison.



a. Diode Laser Engravers





Diode lasers have the lowest optical power compared to other types of lasers.

They are typically 5-15W. However, these can cut and engrave all materials we have discussed. Even this low power is suitable for small businesses. If the power is low, then there will be a few passes required.

xTool has introduced the world's first diode laser module with 20W optical power. The module is very powerful, which can cut up to 10mm plywood in one pass. It does the job quickly and with high precision. It increases the efficiency of engraving and cutting of a diode laser machine.
