CUT 100C AIR Plasma Cutting Machines
The air plasma cutter is a powerful cutting tool that has several advantages over traditional cutting methods.
Product Description
| Model Parameters |
CUT 100C |
| Rated Input Voltage (V) | AC380V |
| Power Frequency(Hz) | 50/60Hz |
| Phase | 3 |
| Rated Input Current（A） | 28 |
| Rated Input Power(KVA) | 18.4 |
| No-load Voltage(V) | 340V |
| Rated load voltage（V） | 120V |
| Cutting Current（A） | CUT:25-100A, MMA:40-200A |
| Rated Duty Cycle %(40℃) | CUT:40%(40℃), MMA:100%(40℃) |
| Efficiency | ≥85% |
| Max Cutting Thickness (Carbon steel)(mm) | 40mm |
| Quality Cutting Thickness (Carbon steel)(mm) | ≤25mm |
| Arc ignition method | HF（Contact/Non-contact） |
| Protection Class | IP21S |
| Dimensions(mm) | 590*370*618 |
| Net Weight(Kg) | 49 |
Inverter air plasma cutter
Built-in air compressor
Features :
IGBT inverter technology ,
User friendly panel ,
Built-in air compressor , easy to operate ,
Optional inner or outer compressor,
Adjustable post-flow gas time ,
Max cutting thickness :40mm
With 2T/4T function
CUT/MMA function
The Air Plasma Cutting Machine is a powerful cutting tool used in metalworking and fabrication industries. It utilizes a high-velocity jet of ionized gas (plasma) to cut through various types of metal. This cutting process is faster and more precise than traditional cutting methods, making it a popular choice in the manufacturing industry.
