200L Jacketed Glass Reactor

The jacketed glass reactors are commonly used in many scientific disciplines for chemical synthesis, process development, post-processing, filtration, purification, evaporation, stirring, dissolution, mixing and extraction operations. Our glass reactors range in size from 1 liter to 200 liters; everything from micro, pilot scale and thousand scale labs to commercial scale production.

Product Description

Please continue to view our 200L jacketed glass reactor.

The jacketed glass reactors are commonly used in many scientific disciplines for chemical synthesis, process development, post-processing, filtration, purification, evaporation, stirring, dissolution, mixing and extraction operations. Our glass reactors range in size from 1 liter to 200 liters; everything from micro, pilot scale and thousand scale labs to commercial scale production. Custom glass reactor systems are designed with a combination of custom and standard components, often designed in collaboration with our customers. Whether you need a pre-configured benchtop workstation or a one-of-a-kind custom chemical process reactor, talk to us about your jacketed glass reactor!



Brief introduction:

The LABSNOVA Jacketed Glass Reactors are mainly used for synthetic reaction, crystallization and concentration of different types of materials in a controlled temperature and vacuum environment.  It finds a multitude of uses in the chemical, pharmaceutical, and biotechnology industries, in research and development, in manufacturing and quality assurance, in laboratories, and in plant construction. We manufacture Glass Reactors from laboratory scale 1-5L to pilot prodution scale 10-200L. Support customization, provide TURNKEY SYSTEMS solution.

LABSNOVA manufacture single layer, double layer and three layers glass reactors. Each reactor features adjustable stirring speeds and a constant pressure feeding funnel that allows you to add material to the vessel at a uniform and controlled speed. The built-in condenser makes it possible to recover some materials, also at a controlled rate of speed. Condenser helps to recover some materials distillated during reaction. Circulating liquid can be filled into the jacket to heat or cool materials inside. Three layers glass reactor with two jackets, the inner jacket is for circulating liquid, and the outer layer should be pumped to vacuum condition for thermal insulation.

Jacketed Glass Reactors (double layer) WKS-200 can be made into system devices with Circulating Water Vacuum Pump, Diaphragm Vacuum Pump, Circulating Chiller, heater chiller.



10 Good reasons to choose LABSNOVA Jacketed Glass reactors

1. All seals are PTFE to increase durability and longevity. PTFE is resistant to a large portion of solvents and chemicals.

2. With GG-17 High Borosilicate Glass that is durable and resistant.

3. Wide range of temperature operations -80°C to 250°C

4. Large condensing area for faster condensing.

5. Durable stainless steel support frame with casters.

6. Speed display, digital temperature display, operate visually and easily.

7. Quite operation, safety features such as over-temperature shut off and dry-run protection.

8. Rugged, High RPM stirring motor for superior stirring power.

9. Excellent price, A solution for any budget.

10. 1 year warranty with fantastic customer service.



Technical Data

Model WKS-10L WKS-20L WKS-30L WKS-50L WKS-80L WKS-100L WKS-150L
Frame material Stainless Steel
Volume 10L 20L 30L 50L 80L 100L 150L
Jacket volume 6L 8L 10L 12L 16L 18L 23L
Number of reactor bottle 6
Working temperature -80 to 250℃
Stirring speed 0~450rpm
Stirring power 90w 90w 120w 120w 120w 200w 750w
Funnel Pressure equalizing
Package size(mm)

1370x590x

800

1480x660x

810

1720x680x

850

1720x680x

850

1900x700x

870

1900x700x

870

1720x680x

850

Package weight(kg) 60 80 88 92 125 125 160
Power source 220v/110v,50-60Hz

 Glass-Reactor- Details.jpg

Glass reactors Details

Glass reactors Turnkey System Solutions

100l-jacketed glass-reactor-trunkey-1-1.jpg

1. 200L Jacketed Glass Reactor WKS-200 + 100L Circulating Chiller WKC-100/30 + Water Vacuum Pump WKP-95B

2. 200L Jacketed Glass Reactor WKS-200 + 100L Circulating Heater WGY-100 + Water Vacuum Pump WKP-95B



Technical Data

Model WKS-10L WKS-20L WKS-30L WKS-50L WKS-80L WKS-100L WKS-150L
Frame material Stainless Steel
Volume 10L 20L 30L 50L 80L 100L 150L
Jacket volume 6L 8L 10L 12L 16L 18L 23L
Number of reactor bottle 6
Working temperature -80 to 250℃
Stirring speed 0~450rpm
Stirring power 90w 90w 120w 120w 120w 200w 750w
Funnel Pressure equalizing
Package size(mm)

1370x590x

800

1480x660x

810

1720x680x

850

1720x680x

850

1900x700x

870

1900x700x

870

1720x680x

850

Package weight(kg) 60 80 88 92 125 125 160
Power source 220v/110v,50-60Hz



Model S212-1L S212-2L S212-3L S212-5L
Frame material Stainless Steel
Volume 1L 2L 3L 5L
Jacket volume 0.4L 0.8L 1.2L 2L
Number of reactor bottle 5
Working temperature -80 to 250℃
Stirring speed 0~800rpm
Stirring power 40w 40w 90w 90w
Funnel Pressure equalizing
Package size(mm)



1200x480x

400



1200x480x

400



1380x500x

400

1380x500x

400



Package weight(kg) 32 32 36 36
Power source 220v/110v,50-60Hz





Turn-key Systems




Process jacketed glass reactors designed for superior performance

The jacketed glass reactor's process chemistry reactors are designed and engineered for ease of use and superior performance. Unless otherwise noted, all of our glass components are manufactured entirely from Class I, Type A borosilicate glass that meets ASTM specification E438 for excellent chemical and thermal resistance. The user-friendly support frames are designed using our "open frame" approach to maximize user accessibility. Frame components include PTFE-coated aluminum bases, cross bracing and fittings, and stainless steel columns for maximum strength and durability.

Jacketed glass reactors are commonly used in chemical synthesis, process development, post-processing, filtration, purification, evaporation, stirring, dissolution, mixing and extraction operations in many scientific disciplines. Our glass reactor vessels range in size from 100 ml to 100 liters; everything from micro, pilot scale and kilo labs to commercial scale production. Custom glass reactor systems are designed using a combination of custom and standard components, often designed in collaboration with our customers. Whether you need a pre-configured benchtop workstation or a unique custom chemical process reactor, specify the jacketed glass reactor as the catalyst for your next reactor.



Jacketed glass reactor

Jacketed glass reactors are designed to perform single and multi-step reactions and filtration in the same glass reactor vessel. They are also used for production and process scale peptide synthesis. Our unique, patent-pending PTFE filter base system eliminates content transfer and significantly reduces losses. The complete filter reactor system is equipped with our innovative "open frame" self-centering support for easy setup and maximum accessibility.

With its cutting-edge design and innovative technology, this glass reactor is the perfect tool for any laboratory or industrial application.

Featuring a robust 200l capacity, this jacketed glass reactor is built to handle even the toughest chemical reactions with ease. The double-layered jacket ensures excellent temperature control and prevents unwanted heat loss, making it the perfect choice for temperature-sensitive applications.

The jacketed reactor design allows for easy cleaning and maintenance, while the transparent glass body offers excellent visibility for monitoring your experiments. Plus, the high-quality borosilicate glass construction ensures superior chemical resistance and durability.

Whether you're working with acids, solvents, or other chemicals, this jacketed glass reactor is up to the task. Don't settle for anything less than the best - choose our glass chemical reactor for all your chemical processing needs.
